Gate valve Socket weld carbon steel TRIM.16 800#
| Model: | Socket weld TRIM 16 | Material body: | Steel ASTM A105N |
| Connection: | Socket weld | Material wedge: | AISI 316 + Stellite GR.6 |
| Pressure: | 136 bars see PDF | Material seat: | AISI 316 + Stellite GR.6 |
| Temperature: | - 29°C to + 425°C see data sheet | Operation: | Hand wheel |
| Design: | To ISO 15761 and API 602 8th |
Brand: | OMB |
| 2 side flow direction |
| Use: Petroleum industry, steam, heavy duty |
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
| SKU: | MXT-1110022000 |
| Body material | Steel ASTM A105N |
| Disc / Ball / Wedge | AISI 316 + Stellite GR.6 |
| Seat | AISI 316 + Stellite GR.6 |
